Specification sheet
Record working width in ft or m, crop and throughput basis, feeding arrangement and the combine model and serial range. Separate buyer target values from supplier-declared values so the source of each number stays visible.
Technical Resources / Purchase review
Headers for combine harvester: documents for a compatibility decision
Organize dimensions, interface records and operating assumptions before accepting a factory alternative. Prairie Link Sourcing uses this evidence to clarify the inquiry; final machine compatibility belongs to the responsible buyer and technician.
DRAWING
REVISION
APPROVAL
REVISION
APPROVAL
Build a document set for the exact assembly
Interface drawing
Request the feeder mounting dimensions, drive coupling, hydraulic connections and control requirements. Label the revision and units. A drawing must show the actual proposed configuration; a generic image cannot settle the connection question.
Service and wear-part record
Ask for knife, guard and drive replacement references with maintenance instructions. Confirm whether fasteners, adapters and tools are supplied or excluded. Keep the installation responsibility and any training scope in the quotation.
Procurement reading and requested supplier files
Our procurement checklist is available as an article. Model-specific manuals, dimensioned drawings and inspection records must be requested from the proposed factory; no unverified manual download is presented here.
Combine parts procurement checklistFields for a consistent quote scope, quantity and destination.Read article →
Supplier drawing and manual pack
Request the exact model, serial applicability and revision in your inquiry.Request documents →
Request the exact model, serial applicability and revision in your inquiry.Request documents →
A repeatable review sequence
| Evidence | Check to record | Release condition |
|---|---|---|
| Working width / capacity | Use ft or m for width and a stated crop, grain moisture and throughput basis for capacity. | Supplier and buyer use the same operating assumptions. |
| Mounting and drive | Compare dimensioned interfaces, power requirements, connection types and clearances. | The responsible technician approves the drawing revision. |
| Blade and wear parts | Compare material specification, thickness, mounting-hole centers and replacement references. | Sample or inspection plan covers the agreed critical dimensions. |
| Commercial boundary | List MOQ, packing, adapters, service documents, freight and installation exclusions. | Budget comparison uses the same currency and whole-order scope. |
Where a sample is needed, agree the measurement method and acceptance tolerance before ordering it. Record instruments, datum points, measured results and the approving person. A static dimensional check cannot establish field durability; any field trial needs a separately agreed crop, operating setup and observation plan.
Compare a direct replacement with an adapted alternative by drawing approval, sample work, installation scope and total cost. A budget-friendly unit may need extra adaptation; a premium preference does not prove better compatibility. Exact price and lead time remain quote-specific.
Put missing evidence into the RFQ
Identify the open specification, required drawing revision, quantity and destination. We can ask factories to respond to the same questions and keep unapproved alternatives separate.
